A-132
ProCurve Wireless Services xl Module Command Line Reference
Support Commands (All Contexts)
• tech-support - Copy extensive system information useful to technical
support for troubleshooting a problem.
– URL - URL to which to copy.
URLs: tftp://<hostname or IP>/path/file
ftp://<user>:<passwd>@<hostname or IP>/path/file
scp://<user>@<hostname or IP>/path/file
Default Setting
N/A
Command Mode
Manager
Example
support diag
This command configures diagnostics. The no command negates the diagnostics.
Syntax
support diag (enable | period )
• enable - Enable in-service diagnostics.
• period - Set diagnostic period.
– <100-30000> - Diagnostic period, default 1000.
Default Setting
Diagnostic Period: 1000
Command Mode
Manager
Example
ProCurve(wireless-services-B)#support copy tech-support
tftp://192.168.1.10/testfile
ProCurve(wireless-services-B)#
ProCurve(wireless-services-B)#support diag enable
ProCurve(wireless-services-B)#
