A-136
ProCurve Wireless Services xl Module Command Line Reference
Support Commands (All Contexts)
support set
This command sets service parameters.
Syntax
support set (command-history | reboot-history | upgrade-history )
• command-history - Set size of command history. Default: 200.
– <10-300> - History size.
• reboot-history - Set size of reboot history. Default: 50.
– <10-100> - History size.
• upgrade-history - Set size of upgrade history. Default: 50.
– <10-100> - History size.
Default Setting
command-history (200), reboot-history (50), and upgrade-history (50)
Command Mode
Manager
Example
support show
This command shows running system information.
Syntax
support show (chassis | cli | command-history | cpu | crash-info | diag | info |
last-passwd | pm | process | reboot-history | rp | sessions | startup-log | temper-
ature | upgrade-history |)
• chassis- Chassis Details.
• cli- Shows CLI tree of current mode.
• command-history - Displays command (except show commands) history.
• cpu - Display system load.
• crash-info- Displays information about core, panic and AP dump files.
– PANIC_FILENAME - Show contents of specified kernel panic file.
• diag - Diagnostics.
– hardware - Shows the system hardware configuration.
ProCurve(wireless-services-B)#support set command-history
100
ProCurve(wireless-services-B)#
