A-137

ProCurve Wireless Services xl Module Command Line Reference

Support Commands (All Contexts)

– period - Shows the period (ms) for the in service diagnostics.

– stats - Shows the curent diagnostics statistics.

• info - Shows snapshot of available support information.

• last-passwd - Displays last password used to enter shell.

• pm - Process Monitor.

– history - States changes for a process, the time they happened and the

events that triggered them.

+WORD - Process name.

+all - All processes.

• process - Displays process activity in real time.

• reboot-history - Shows reboot history.

• rp- Radio-port serviceability parameters.

– adopt-history - Radio-port adopt-history.

+XX-XX-XX-XX-XX-XX - Radio-port MAC.

• sessions - Displays current active open connections.

• startup-log - Shows startup log.

• temperature - Displays CPU temperature.

• upgrade-history - Shows upgrade history

Command Mode

N/A

Command Mode

Manager

Examples

ProCurve(wireless-services-B)#support show command-history

Configured size of command history is 100

Date & Time User Location Command

=====================================================================

Feb 27 15:17:24 2006 0 vty 130 support set command-history 100

Feb 27 15:08:47 2006 0 vty 131 wireless

Feb 27 15:08:47 2006 0 vty 131 config t

Feb 27 15:08:47 2006 0 vty 131 interface eth0

Feb 27 15:08:47 2006 0 vty 131 config t

Feb 27 15:02:25 2006 0 vty 130 support rp force-dump

Feb 27 14:59:01 2006 0 vty 130 support prompt crash-info

Feb 27 14:55:02 2006 0 vty 130 support pm sys-restart

Feb 27 14:37:54 2006 0 vty 131 support diag enable
