A-138
ProCurve Wireless Services xl Module Command Line Reference
Support Commands (All Contexts)
ProCurve(wireless-services-B)#support show info
4.0M out of 4.0M available for logs.
6.7M out of 8.2M available for history.
3.5M out of 4.8M available for crashinfo.
List of Files:
/flash/crashinfo/ccsrvr.dump 0 Nov 1 09:57
/var/log/messages.log 0 Feb 27 09:09
/var/log/startup.log 11.2k Feb 27 09:09
/var2/history/command.history 834 Feb 27 15:17
/var2/history/reboot.history 3.4k Feb 27 09:09
/var2/history/upgrade.history 1.6k Nov 22 15:18
Please export these files or delete them for more space.
ProCurve(wireless-services-B)#support show rp adopt-history
AP MAC Timestamp Event Reason
========================================================================
00-14-C2-A0-0B-05 Oct 19 10:19:22 2005 adoption NULL
00-14-C2-A0-0B-05 Nov 22 17:38:20 2005 adoption NULL
00-14-C2-A0-0B-05 Nov 22 15:26:18 2005 adoption NULL
00-14-C2-A0-0B-05 Nov 22 08:49:42 2005 adoption NULL
00-14-C2-A0-0B-05 Nov 22 08:08:51 2005 adoption NULL
ProCurve(wireless-services-B)#support show temperature
Value of temperature in degree C : 36
ProCurve(wireless-services-B)#support show upgrade-history
Configured size of upgrade history is 50
Date & Time Old Version New Version Status
=====================================================================
Nov 22 15:17:32 2005 WS.01.XX.0551Swami~ WS.01.XX.0551Swami Successful
Nov 21 13:09:25 2005 WS.01.XX.0551n WS.01.XX.0551Swami Successful
Nov 21 13:09:05 2005 WS.01.XX.0551n WS.01.XX.0551n Unable to get update file.
td
Nov 18 11:30:22 2005 WS.01.XX.0548n~ WS.01.XX.0551n Successful
Nov 18 11:28:29 2005 WS.01.XX.0548n~ WS.01.XX.0548n~ Unable to get update
file.d
Nov 17 15:27:19 2005 WS.01.XX.0548n~ WS.01.XX.0548n Successful
Nov 17 15:17:28 2005 WS.01.XX.0548n~ WS.01.XX.0548n Successful
Nov 15 16:43:22 2005 WS.01.XX.0548n~ WS.01.XX.0548n Successful
Nov 15 15:31:05 2005 WS.01.XX.0526n WS.01.XX.0548n Successful
Nov 15 15:26:06 2005 WS.01.XX.0526n WS.01.XX.0526n Unable to get update file.
te
Nov 02 17:15:16 2005 WS.01.XX.0526jim WS.01.XX.0526n Successful
Nov 02 12:16:54 2005 WS.01.XX.0526n WS.01.XX.0526jim Successful
Oct 31 10:42:48 2005 WS.01.XX.0505j WS.01.XX.0526n Successful
Oct 31 09:58:44 2005 WS.01.XX.0505j WS.01.XX.0505j Bad file, image header
contas
-- MORE --, next page: Space, next line: Enter, quit: Control-C
