A-141
ProCurve Wireless Services xl Module Command Line Reference
Support Commands (Wireless)
Support Commands (Wireless)
This section details the support commands available for the Wireless parameters.
support wireless dump-core
This command creates a core file of the ccsrvr process.
Syntax
support wireless dump-core
Default Setting
Enabled
Command Mode
Manager
Example
support wireless dump-state
This command creates a ccsrvr.dump file in nvram with internal state information.
Syntax
support wireless dump-state
Default Setting
Enabled
Command Mode
Manager
ProCurve(wireless-services-B)(config-wireless)#support
wireless dump-core
ProCurve(wireless-services-B)(config-wireless)#
