A-142
ProCurve Wireless Services xl Module Command Line Reference
Support Commands (Wireless)
Example
support wireless rate-scale
This command enables wireless rate scaling. The no command negates the configu-
ration of the wireless parameters.
Syntax
support wireless rate-scale
no support wireless rate-scale
• rate-scale - Enable wireless rate scaling (default).
Default Setting
Enabled
Command Mode
Manager
Example
support wireless spectrum-management
This command enables 802.11h+d spectrum management on all 802.11a wireless
LANs. The no command negates the configuration of the wireless parameters.
Syntax
support wireless spectrum-management
no support wireless spectrum-management
• spectrum-management - Enable 802.11h+d spectrum management on all
802.11a wireless LANs (default).
Default Setting
Enabled
ProCurve(wireless-services-B)(config-wireless)#support
wireless dump-state
ProCurve(wireless-services-B)(config-wireless)#
ProCurve(wireless-services-B)(config-wireless)#support
wireless rate-scale
ProCurve(wireless-services-B)(config-wireless)#
