A-143
ProCurve Wireless Services xl Module Command Line Reference
Support Commands (Wireless)
Command Mode
Manager
Example
support wireless tkip-countermeasures
This command enables countermeasures on all tkip-enabled wireless LANs. The no
command negates the configuration of the wireless parameters.
Syntax
support wireless tkip-countermeasures
no support wireless tkip-countermeasures
• tkip-countermeasures - Enable countermeasures on all tkip-enabled wire-
less LANs (default).
Default Setting
Enabled
Command Mode
Manager
Example
ProCurve(wireless-services-B)(config-wireless)#no support
wireless spectrum-management
ProCurve(wireless-services-B)(config-wireless)#
ProCurve(wireless-services-B)(config-wireless)#no support
wireless tkip-countermeasures
ProCurve(wireless-services-B)(config-wireless)#
