11
CHAPTER
1
System Components
The MSA2000 Family 2012sa Modular Smart Array and MSA2000 Drive Enclosure
are high-performance storage solutions that combine outstanding performance with
high reliability, availability, flexibility, and manageability.
Supported configurations include a controller enclosure with or without attached
drive enclosures. A controller enclosure can contain two controllers that interact and
provide failover capability for the data path. The controller enclosure can use SATA
or SAS disk drive modules.
This chapter provides information about the system components, and includes the
following topics:
■ “System Management Software” on page 12
■ “Hardware Components and LEDs” on page 13
Important – This product contains one or more features which allow remote
connection to HP or HP’s authorized representatives for the benefit of the customer
(such as troubleshooting). This feature is enabled by default. Your use of this
product indicates your acceptance of this feature. This feature cannot be disabled.
