Chapter 1 System Components 13
Hardware Components and LEDs
This section describes the main hardware components of your storage system
enclosures.
Controller Enclosure Components and LEDs
Table 1-1 describes the controller enclosure components.
Table 1-1 Controller Enclosure Components
Description Quantity
Controller (I/O) module 1 or 2
1
1 Air-management system drive blanks or I/O blanks must fill empty slots to maintain optimum airflow through the chassis.
SAS or SATA drive module 2–12 per enclosure
AC power-and-cooling module 2 per enclosure
3-Gbps, 4-lane SAS host ports (SFF-8088
standard interface)
2 per controller module
3-Gbps, 4-lane SAS expansion port (SFF-
8470 standard interface)
1 per controller module
Ethernet port (RJ-45) 1 per controller module
CLI port (RS-232 micro-DB9) 1 per controller module
