Chapter 1 System Components 23
Expansion
module
Fault/Service
Required
Amber On A fault has been detected or a service action
is required.
Blink Indicates a hardware-controlled power up or
a cache flush or restore error.
Expansion
module
OK Green Off Expansion module is not OK.
On Expansion module is operating normally.
Blink System is booting.
Expansion
module
SAS Out port
status
Green Off The port is empty or the link is down.
On The port link is up and connected.
Table 1-8 Drive Enclosure LEDs (Back) (Continued)
Location LED Color State Description
