HP StorageWorks 2012sa Modular Smart Array user (488320-004, March 2013)
Table Of Contents
- Contents
- About This Guide
- 1
- System Components
- 2
- Installing and Cabling Enclosures
- 3
- Connecting Hosts
- 4
- Configuring a System for the First Time
- 5
- Troubleshooting
- Fault Isolation Methodology
- Correcting Enclosure IDs
- Using System LEDs to Diagnose Problems
- Is the front panel Fault ID amber?
- Is the controller back panel OK LED off?
- Is the controller back panel Fault/Service Required LED amber?
- Are both drive module LEDs, Online/Activity, and Fault/UID LEDs off?
- Is the drive module Fault/UID LED blinking amber?
- Is a connected port’s Host Link Status LED off?
- Is a connected port’s Expansion Port status LED off?
- Is a connected port’s Ethernet link status LED off?
- Is the power-and-cooling module AC Power Good LED off?
- Is the power-and-cooling module DC Voltage/Fan Fault/Service Required LED amber?
- Is the drive enclosure back panel OK LED off?
- Is the drive enclosure Fault/Service Required LED amber?
- Isolating a Host-Side Connection Fault
- Isolating a Controller Module Expansion Port Connection Fault
- Resolving Voltage and Temperature Warnings
- A
- Environmental Requirements and Specifications
- B
- Regulatory Compliance and Safety
- Index
26 HP 2012sa Modular Smart Array user guide • January 2013
Safety Precautions
For your protection, observe the following safety precautions when setting up your
equipment:
■ Install the system in accordance with the local safety codes and regulations at the
facility site. Follow all cautions and instructions marked on the equipment.
■ Ensure that the voltage and frequency of your power source match the voltage
and frequency inscribed on the equipment’s electrical rating label.
■ Never push objects of any kind through openings in the equipment. Dangerous
voltages may be present. Conductive foreign objects could produce a short circuit
that could cause fire, electric shock, or damage to your equipment.
Note – Do not make mechanical or electrical modifications to the product. The
vendor is not responsible for the safety or regulatory compliance of a modified
product.
Caution – Two people are needed to lift and move the enclosure. Use care to avoid
injury. An enclosure with all drives installed can weigh 65 pounds (29.5 kilograms).
Caution – Electrostatic discharge can damage sensitive components. Be sure you
are properly grounded before touching a static-sensitive component or assembly.
