Chapter 2 Installing and Cabling Enclosures 29
Figure 2-1 provides a visual overview of the rackmount kit assembly components
and corresponds to the steps that follow.
Figure 2-1 Overview of Standard 19-Inch EIA Rackmounting Components
#10-32 x 5/8 truss screws
Threaded PEMs (4)
Rear bracket connected to rack
#10-32 x 5/8 truss screws
Side bracket
(Step 6)
(Step 5)
(Step 8)
(Step 9)
#8-32 x 3/16 flathead screws
#8-32 x 1/4 panhead screws
