Chapter 4 Configuring a System for the First Time 45
As shown in the following example, network parameters, including the IP address,
gateway address, and subnet mask are displayed for each controller.
8. In the host computer's command window, type the following command to verify
Ethernet connectivity, first for controller A and then for controller B:
If you cannot access your system three minutes after changing the IP address,
your network might require you to restart the management controller using the CLI.
When you restart a management controller, communication with it is temporarily
lost until it successfully restarts.
Type the following command to restart the management controller on both
controllers:
9. After you have verified Ethernet connectivity, disconnect the serial cable and exit
the emulator.
Network Parameters Controller A
--------------------------------
IP Address : 192.168.0.10
Gateway : 192.168.0.1
Subnet Mask : 255.255.0.0
MAC Address : 00:00:FF:D5:01:4D
Addressing Mode : Manual
Network Parameters Controller B
--------------------------------
IP Address : 192.168.0.11
Gateway : 192.168.0.1
Subnet Mask : 255.255.0.0
MAC Address : 00:C0:FF:D5:01:15
Addressing Mode : Manual
ping IP-address
restart mc both
