56 HP 2012sa Modular Smart Array user guide • January 2013
Using System LEDs to Diagnose Problems
This section describes possible reasons and actions to take when an LED indicates a
fault condition. See “System Components” on page 11 for descriptions of all LED
statuses.
Is the front panel Fault ID amber?
Is the controller back panel OK LED off?
Answer Possible Reasons Actions
No System functioning properly. No action required.
Yes A fault condition exits. • Check the LEDs on the back of the
controller to narrow the fault to a
FRU, connection, or both.
• Check the event log for specific
information regarding the fault.
Answer Possible Reasons Actions
No System functioning properly. No action required
Yes • The controller module is not
powered on.
• The controller module has
failed.
• Check that the controller module is
fully inserted and latched in place,
and that the enclosure is powered
on.
• Check the event log for specific
information regarding the failure.
