60 HP 2012sa Modular Smart Array user guide • January 2013
Is a connected port’s Ethernet link status LED off?
Is the power-and-cooling module AC Power Good
LED off?
Answer Possible Reasons Actions
No System functioning properly. No action required.
Yes The link is down. Use standard networking
troubleshooting procedures to isolate
faults on the network.
Answer Possible Reasons Actions
No System functioning properly. No action required.
Yes The module is not receiving
adequate power.
• Verify that the power cord is
properly connected and check the
power source it is connected to.
• heck that the power-and-cooling
supply FRU is firmly locked into
position.
• Check the event log for specific
information regarding the fault.
• Isolate the fault.
• Contact an authorized service
provider for assistance.
