Appendix A Environmental Requirements and Specifications 75
Environmental Requirements
Table A-2 Rackmount Enclosure Weights
Specification Rackmount
2012sa Modular Smart Array (12 drives)
•SAS drives
•SATA drives
64.5 lb (29.3 kg)
65.5 lb (29.8 kg)
MSA2000 Drive Enclosure (12 drives)
•SAS drives
•SATA drives
62 lb (28.2 kg)
63 lb (28.6 kg)
Table A-3 Operating Environmental Specifications
Specification Range
Altitude To 9842 feet (3000 meters), derate 35.6° F (2° C) for every
3281 feet (1 km) up to 9842 feet (3000 meters)
Relative Humidity 10% to 90% RH, 104° F (40° C) non condensing
Temperature 41° F to 104° F (5° C to 40° C)
Shock 5.0 g, 10 ms, half-sine
Vibration 0.5 g, 1 octave/minute, 5 Hz to 500 Hz to 5 Hz, swept-sine
