HP Storage Essentials V5.00.01 installation guide (T4283-96011, January 2006)
Table Of Contents
- HP
- Storage Essentials 5.00.01 Installation Guide
- Contents
- Overview
- Installing the Management Server on Microsoft Windows
- Discovering Filers, Tape Libraries, Switches and Storage Systems
- Deploying CIM Extensions
- Installing the CIM Extension for IBM AIX
- Installing the CIM Extension for SGI ProPack for Linux
- Installing the CIM Extension for HP-UX
- Installing the CIM Extension for SUSE and Red Hat Linux
- Installing the CIM Extension for OpenVMS
- Installing the CIM Extension for HP Tru64 UNIX
- Installing the CIM Extension for SGI IRIX
- Installing the CIM Extension for Sun Solaris
- Installing the CIM Extension for Microsoft Windows
- Discovering Applications, Backup Servers and Hosts
- Managing Security
- Troubleshooting
Installing the Management Server on Microsoft Windows10
• Install the database on the computer you plan to install the management server.
• For double-byte languages, the Oracle installation provides an extra dialog screen, which is for
the Oracle Net Configuration Assistant. This screen requires the user to select the check box and
click Next. Once you clicked Next, a command window appears. The command window will
close itself once the operation running inside the command window completes.
The installation of Oracle is comprised of two steps:
• Installing the database - See ”Installing the Database” on page 10.
• Installing the Oracle patch - See ”Installing the Oracle Patch (Windows)” on page 10.
Installing the Database
To install the database:
1. Copy the Oracle file set (Oracle disks 1, 2, and 3) and the patch directories to a local drive or
run them from the CD-ROMs.
NOTE: If you copy the files, put them in a path that does not contain any spaces. The
installPatch.cmd file requires file paths that do not require spaces.
2. Do one of the following:
• From the CD-ROM - Allow the CD to autorun. If you must run the installation manually,
double-click inst.cmd found in the /AppIQ directory instead of setup.exe. The
installation is spread over several CD-ROMs. During the installation, you are asked to switch
CD-ROMs.
• From the Oracle_1 file set you copied to the hard drive - Double-click inst.cmd found in the
/AppIQ directory instead of setup.exe.
3. When you are asked if you want to set the ORA_HOME environment variable, click Yes if it has
not been set or you want to change the location.
4. Enter the directory and its path that will contain the database, for example: D:\database
where D:\database is the directory that will contain the database.
IMPORTANT: Do not specify a directory with spaces, such as the Program Files directory or
any directories under Program Files.
5. Select No Database Creation when you are asked if you want to create a database.
Select the defaults for all three CDs or file sets.
Installing the Oracle Patch (Windows)
The steps provided in this section describe how to install Oracle Server Patch 9.2.0.6.0.
