HP Storage Essentials V5.00.01 installation guide (T4283-96011, January 2006)
Table Of Contents
- HP
- Storage Essentials 5.00.01 Installation Guide
- Contents
- Overview
- Installing the Management Server on Microsoft Windows
- Discovering Filers, Tape Libraries, Switches and Storage Systems
- Deploying CIM Extensions
- Installing the CIM Extension for IBM AIX
- Installing the CIM Extension for SGI ProPack for Linux
- Installing the CIM Extension for HP-UX
- Installing the CIM Extension for SUSE and Red Hat Linux
- Installing the CIM Extension for OpenVMS
- Installing the CIM Extension for HP Tru64 UNIX
- Installing the CIM Extension for SGI IRIX
- Installing the CIM Extension for Sun Solaris
- Installing the CIM Extension for Microsoft Windows
- Discovering Applications, Backup Servers and Hosts
- Managing Security
- Troubleshooting
Discovering Filers, Tape Libraries, Switches and Storage Systems42
3. Select Step 1 at the top of the page.
4. Do one of the following:
• Select the IP addresses and/or IP ranges you want to remove from the list. Then, click the
Delete button.
• Click the button corresponding to the elements you want to remove from the Addresses to
Discover list.
IMPORTANT: The elements associated with these addresses are not removed from the
management server. See ”Deleting Elements from the Product” on page 92 for information
about how to remove an element from the management server.
Importing Discovery Settings from a File
If you have a previous discovery list you can import it, rather than re-entering the information.
Discovery from HP SIM
To import a list of hosts:
NOTE: Refer to the HP SIM documentation for more information about importing a list of
discovered elements.
1. Click Options > Discovery.
2. Click the Hosts File tab.
3. Click the New button.
4. In the Hosts file name field, enter a name for the new hosts file. This field is required.
5. Under Initialize contents select Systems loaded from hosts file. Enter the file name and
location (for example, c:\ doc.txt) or click Browse to browse to the location of the hosts file. This
option reads the contents of the specified file and displays it in the Contents window.
6. If you did not select Empty File, click Initialize Now to load the hosts file. Otherwise, enter the
contents of the hosts file in the Contents section.
7. Click OK to save the hosts file, or click Cancel to cancel any changes you have made.
Discovery from HP SE
The import discovery settings feature lets you import the following information to the Discovery list:
• IP addresses to discover
• Default user names and passwords, which are encrypted
• Discovery information for applications
To prevent re-entering the information for each management server instance, you can import the
same file for multiple management server instances.
