Using Command Console
41Command Console V2.5 User Guide
■ You can use folders to group systems and other general folders. Note that you
cannot use folders to group controllers.
For example, in Figure 8, the general folder Storage on the First floor was created
and two agent systems were placed in the folder. If a system in the folder is at a
critical state, the status of the folder displays the same critical state.
Note: For a description of the Command Console Navigation tree, refer to the “Quick
Tour” in the introduction of the Command Console Client online Help.
About the Navigation Tree Icons
The Navigation tree icons listed in Table 7 change to show system status. The
Navigation window status bar, located in the lower-left corner, summarizes the
host system connection status.
Table 7: Description of Icons in Navigation Window Status Bar
Icon Description
Indicates the number of disconnected systems
Indicates the number of fully functional systems
Indicates the number of degraded systems
Indicates a critically failed system
