45Command Console V2.5 User Guide
3
Setting Up Notification
Required Components for Notification
Table 8 lists the notification options available with SWCC and the components
required for each option.
Table 8: Required Components for Notification
Notification Option Required Components
Navigation tree Client and Agent
Pager Client and Agent
Email notification (applies to certain
agents)
Agent
Event logging Agent
SWCC with third-party storage
management program
Agent and third-party storage
management program
