Setting Up Notification
54 Command Console V2.5 User Guide
Using SWCC with a Third-Party Storage Management Program
To use SWCC with a third-party storage management program:
1. Add the name of the computer on which the third-party storage management
program resides to the Agent’s list of client system entries. Select SNMP as
the notification scheme. The Agent sends SNMP traps to every client system
on its list.
For more information on how to add client systems, see the Installation and
Configuration Guide for your Agent.
2. Use the compiler that came with your third-party storage management
program to compile the Management Information Base (MIB) file,
hs-agent.mib in this kit.
Note: Depending on the third-party software, you may need to perform additional
steps. Refer to the third-party storage management program documentation.
