87Command Console V2.5 User Guide
6
Integrating SWCC with Insight
Manager
You can use the HSGxx Storage windows within Insight Manager V4.23 or later
to monitor and manage the controllers. If your HSGxx controller uses Array
Controller Software (ACS) V8.5 or later, you need to install the integration patch
(HSG80 Shim). HSG80 Storage Window V2.4 is required to run the integration
patch.
