Setting Up Notification
48 Command Console V2.5 User Guide
Note: All codes are numeric-only; alphanumeric pager codes are not supported.
Setting Up User Profiles
1. Click Options > Event Notification > User Profiles.
2. Click New.
3. Type a name. You can also enter a description.
4. Click the Pager tab.
5. Choose Enabled to enable paging to this person.
6. Enter the phone number for your pager in the Pager Number field, along
with any prefixes required to reach the outside phone system.
Optionally, you can use one or more commas to specify a wait intervals for
numeric pager numbers. Each comma causes the pager dialer to wait two
seconds before sending the PIN to the paging company. An example is: 8,,1,
800,5551212. In this example, there is a 4-second delay between the 8 and the
1.
Table 10: Default Pager Codes
Critical Event Code Notes
Disk Fault 1000 Physical device failure
Power Supply Fault 1002
Fan Fault 1003
Battery Fault 1004
Temperature Fault 1005
Controller Fault 1006 The controller detected an
internal fault
Communication Fault 1007 Agent cannot talk to the
subsystem.
Other controller fault 1008 One controller is
reporting a fault on the
other.
External fault 1009
LUN Fault 1010 Virtual disk failure
