Using the Storage Window
68 Command Console V2.5 User Guide
Configuring a Controller
Your controller’s operating parameters are stored under six tabs in the Controller
Properties window, which you can access by one of two methods:
■ Double-clicking a controller icon in the Storage window
■ Right-clicking a controller icon in the Storage window and choosing
Properties.
A change in some controller settings requires that you restart. The program
prompts you to confirm the restart.
Modifying the General Properties of the Controller
The properties of the top and bottom controllers, such as type, serial number,
SCSI address, firmware revision, hardware revision, and common parameters are
stored under the General tab.
To configure the general properties of the controller, click the General tab. Refer
to step 12 for a description of each general property.
