Corrective ActionMeaningError
StartSnapshotSet was called when another
snapshot set in the process of being cre-
ated.
0x80042316LVSS_E_SNAPSHOT_SET_IN_PROGRESS
AddToSnapshotSet was called on a volume
that has already reached its maximum
number.
0x80042317L
VSS_E_MAXIMUM_NUMBER_ OF_SNAP-
SHOTS_REACHED
The Writer infrastructure is not operating
properly. Check that the Event Service and
the Volume Snapshot Service are started
and check for errors associated with these
services in the error log.
0x80042318LVSS_E_WRITER_INFRASTRUCTURE
A writer did not respond to a GetWriter-
Status call. This means that the process
containing the writer died or is hung.
0x80042319LVSS_E_WRITER_NOT_RESPONDING
A writer has already successfully called the
Subscribe function. It cannot call subscribe
multiple times.
0x8004231ALVSS_E_WRITER_ALREADY_SUBSCRIBED
Attempt to use an unsupported context.0x8004231BLVSS_E_UNSUPPORTED_CONTEXT
Calling ChangeDiffAreaMaximumSize.0x8004231DLVSS_E_VOLUME_IN_USE
Calling AddDiffArea.0x8004231EL
VSS_E_MAXIMUM_DIFFAREA_ ASSOCI-
ATIONS_REACHED
Calling EndPrepareSnapshots, ChangeDif-
fAreaMaximumSize.
Indicates that there are no supported LDEVs
to create snapshots.
0x8004231FLVSS_E_INSUFFICIENT_STORAGE
Calling ImportSnapshots, no volumes were
successfully imported.
0x80042320LVSS_E_NO_SNAPSHOTS_IMPORTED
Calling ImportSnapshots, some volumes
were not successfully imported.
0x00042320LVSS_S_SOME_SNAPSHOTS_NOT_IMPORTED
Indicates that the snapshot contains only a
subset of the volumes needed to correctly
backup an application component.
0x800423F0L
VSS_E_WRITERERROR_ INCONSISTENTSNAP-
SHOT
Indicates that the writer failed due to an out
of memory, out of handles, or other re-
source allocation failure.
0x800423F1LVSS_E_WRITERERROR_OUTOFRESOURCES
Indicates that the writer failed due to a
timeout between freeze and thaw.
0x800423F2LVSS_E_WRITERERROR_TIMEOUT
Indicates that the writer failed due to an
error that might not occur if another snap-
shot is created.
0x800423F3LVSS_E_WRITERERROR_RETRYABLE
Indicates that the writer failed due to an
error that most likely would occur if another
snapshot were created.
0x800423F4LVSS_E_WRITERERROR_NONRETRYABLE
