9. Click Run Now. The Task Results page appears.
NOTE: Click Schedule to run this task at a later time.
NOTE: The Configure or Repair Agents tool can update multiple target systems. The log results indicate
whether the repair attempt was successful.
The Task Results page displays the following information:
• Status This field displays the details for each target system within a task instance.
• Exit Code This field represents the success or failure of an executable program. If the return value
is zero or a positive value, the executable ran successfully. If a negative value is returned, the
executable failed. This exit code does not indicate that all configuration attempts were successful.
It is possible for some to succeed but some to fail.
• Target Name This field displays the name/IP address of the target.
• The stdout tab This tab displays the output text information.
• The stderr tab This tab displays information if the executable experienced an error.
• View Printable Report You can print reports for the selected target system or for all target systems
associated with the task instance.
To print a report:
a. Click View Printable Report.
An Options Message box appears.
b. Select a report.
c. Click OK to display the report, or click Cancel to return to the View Task Results page.
10. If the Management HTTP Server is installed on target systems, the login credentials are updated in the
Management HTTP Server password file.
Like other HP SIM tools, you can configure the Configure or Repair Agents tool to run on a schedule or
manually. Only one instance of Configure or Repair Agents tool can run at a time.
Setting up managed storage systems
Storage Management Initiative Specification (SMI-S) is a Storage Networking Industry Association (SNIA)
standard that enables interoperable management for storage networks and storage devices. HP SIM uses
this standard to discover and manage the storage systems it supports.
You must have a storage system’s WBEM SMI-S provider installed and configured on a managed node for
HP SIM to discover SAN storage. This includes storage devices such as Fibre Channel disk arrays, switches,
tape libraries, or hosts (with Fibre Channel host bus adapters.)
See the HP SIM SMI-S Provider webpage, http://www.hp.com/go/hpsim/providers, to view the latest
information regarding HP SIM support for a particular device. This webpage offers information on obtaining,
installing, and configuring SMI-S providers.
Installing SMI-S providers
Each storage vendor provides the SMI-S provider and installation instructions for its storage system. The
webpage referenced in the previous section provides information on obtaining SMI-S providers. Also, consult
the storage vendor’s website or representative for more information regarding their SMI-S providers. For
each storage system:
1. Verify that the applicable SMI-S provider is installed.
2. If the SMI-S provider is not installed, obtain and install it per the vendor’s installation instructions.
Verifying SSL
HP SIM requires that Secure Sockets Layer (SSL) is enabled for the SMI-S provider in order to discover and
manage the storage system that the provider supports. Verify that SSL is enabled for each SMI-S provider.
