HP SIM service Information:
TRUE | FALSE
The following flag is used to configure an Oracle database during the silent installation:
dbOracle
TRUE - to use an Oracle database
FALSE - not to use an Oracle database
NOTE: When dbOracle is set to TRUE, installSQLEXPR should be set to false.
When installSQLEXPR is set to TRUE, dbOracle should be set to false.
The dbDomain and dbInstance parameters should not be set (left blank).
dbOracleJARFile - must be specified when using an Oracle database. This is used to provide the
location of the JDBC driver to be used to connect to the Oracle database.
For example, <dbOracleJARfile>c:\ojdbc14.jar</dbOracleJARfile>
<svcuserName>
Provide a valid local or domain user account which is a member of the local admins group.
<svcDomain>
Provide the domain for the user account.
Installation Location:
<baseInstallLocation>
and
<hpsimInstallLocation>
define the installation location of HP SIM and the partner components. The base installation location is the
main directory that HP SIM and the partner components are installed to. OpenSSH, HP ProLiant Essentials
Virtual Machine Management Pack is installed in the
<baseInstallLcation>
specified in silent.xml. HP SIM will be installed in
<hpsimInstallLocation>
specified in silent.xml. If the silent install finds a previous HP SIM installation on the target system, that location
will be used instead HP System Management Homepage at %system root drive%\hp\hpsmh.WMI
Mapper at %system root drive%\program Files\The open group\WMI Mapper.
<allowReboot>
Set this to true or false as desired. A server reboot is recommended after installing HP SIM and partner
components. The silent.xml lists all the components with their product IDs for install. Set the
<install>
value to true to install.
NOTE: HP SIM and HP System Management Homepage are always installed even if their
<install> is set to false.
IMPORTANT: For a Silent install, the service or database user name and/or domain name containing
special characters, such as: &, <, >, ', " must be escaped appropriately as below in the silent.xml file:
& &
< <
> >
' '
" "
For example, for a user name such as user&1, the entry in silent.xml would be user&1.
Silent install 43
