HP-UX WBEM LVM Provider Datasheet

Page 6
command, “VG Write Access” field.
uint32 Allocated Local to HPUX_VolumeGroup HP-UX: Allocated space in the volume group in number
of physical extents. Obtained using the vgdisplay
command, “Alloc PE” field.
uint32 Capacity Local to HPUX_VolumeGroup HP-UX: Capacity of the whole volume group in number
of physical extents. Obtained using the vgdisplay
command, “Total PE” field.
string Caption Inherited from CIM_ManagedElement HP-UX: The Pool ID of the volume group.
string Description Inherited from CIM_ManagedElement HP-UX: Textual description of the object.
uint32 FreeSpace Local to HPUX_VolumeGroup HP-UX: Number of free physical extents in the volume
group. Obtained using the vgdisplay command, “Free
PE” field.
uint32 MaxNumberOfLVs Local to HPUX_VolumeGroup HP-UX: Maximum number of definable logical volumes in
the volume group. Obtained using the vgdisplay
command, “Max LV” field.
uint32 MaxNumberOfPVs Local to HPUX_VolumeGroup HP-UX: Maximum number of definable physical volumes
in the volume group. Obtained using the vgdisplay
command, “Max PV” field.
uint32 MaxPEsPerPV Local to HPUX_VolumeGroup HP-UX: Number of maximum allocatable physical extents
from the physical volume. Obtained using the vgdisplay
command, “Max PE per PV” field.
uint32 NumberOfActiveLVs Local to HPUX_VolumeGroup HP-UX: Number of current active logical volumes in the
volume group. Obtained using the vgdisplay command,
“Open LV” field.
uint32 NumberOfActivePVs Local to HPUX_VolumeGroup HP-UX: Number of current active physical volumes in the
volume group
uint32 NumberOfDefinedLVs Local to HPUX_VolumeGroup HP-UX: Number of current defined logical volumes in the
volume group. Obtained using the vgdisplay command,
“Cur LV” field.
uint32 NumberOfDefinedPVs Local to HPUX_VolumeGroup HP-UX: Number of current defined physical volumes in
the volume group. Obtained using the vgdisplay
command, “Cur PV” field.
uint32 NumberOfPVGroups Local to HPUX_VolumeGroup HP-UX: Total number of physical volume groups in the
volume group. Obtained using the vgdisplay command,
“Total PVG” field.
uint32 NumberOfVGDAs Local to HPUX_VolumeGroup HP-UX: Number of Volume Group Descriptor Areas in
the volume group. Obtained using the vgdisplay
command, “VGDA” field.
uint16[] OperationalStatus Inherited from
CIM_ManagedSystemElement
HP-UX: Operational status of the volume group. For
example, if VGStatus is "available" then “2” is added to
OperationalStatus array.
If VGStatus is "unavailable" then “13” is added to
OperationalStatus array.
VGStatus is obtained using the vgdisplay command, “VG
Status” field.
