HP-UX WBEM LVM Provider Datasheet

Page 7
uint32 PESize Local to HPUX_VolumeGroup HP-UX: Size of the fundamental physical extent in Mbytes
uint32 PESizeBytes Local to HPUX_VolumeGroup HP-UX: Size of the fundamental physical extent in bytes.
Obtained using the vgdisplay command, “PE Size” field.
uint64 RemainingManagedSpace Inherited from CIM_StoragePool HP-UX: Remaining amount of raw storage (in bytes) from
the TotalManagedSpace of this storagePool.
uint32 SparePVSInUse Local to HPUX_VolumeGroup HP-UX: Total number of spare physical volumes that are
active in place of a failed physical volume. Obtained
using the vgdisplay command, “Total Spare PVs in use”
field.
uint64 TotalManagedSpace Inherited from CIM_StoragePool HP-UX: Total amount of raw storage (in bytes) managed
by this StoragePool.
uint32 TotalSparePVs Local to HPUX_VolumeGroup HP-UX: Total number of physical volumes that are
designated as spares for the volume group. Obtained
using the vgdisplay command, “Total Spare PVs” field.
string VGStatus Local to HPUX_VolumeGroup HP-UX: VG Status of the volume group
Associations
supported by this
provider
This provider supports the HPUX_LVBasedOnPV, HPUX_PVInVG, HPUX_PVGInVG, HPUX_PVInPVG
associations. Tables 5 to 8 describe the associations supported by the provider.
Table5: HPUX_LVBasedOnPV Association Properties - HPUX_LVBasedOnPV is an association describing the Physical Volumes used in creating a
Logical Volume.
Table 5 describes the properties of the HPUX_LVBasedOnPV association class. It has three columns. The first is the property name (including type
and units), the second is the property inheritance (indicating which class or super class defines the property), and the third is the property’s
description and value. Each row describes a property. Note: while some properties in the table are marked with the “Write” qualifier (based on
their designation in the DMTF CIM schema), all properties are in fact read-only for this version of the HP-UX LVM Provider.
Property Name Property Inheritance Property Description (and value)
HPUX_PhysicalVolume REF Antecedent
[key]
Local to HPUX_LVBasedOnPV HP-UX: Has the lower level StorageExtent.
HPUX_LogicalVolume REF Dependent
[key]
Local to HPUX_LVBasedOnPV HP-UX: Has the higher level StorageExtent.
Table6: HPUX_PVInVG Properties - HPUX_PVInVG is an association describing the Physical Volumes used in creating a Volume Group
Table 6 describes the properties of the HPUX_PVInVG association class. It has three columns. The first column lists the property name (including
type and units), the second is the property inheritance (indicating which class or super class defines the property), and the third discusses the
property description and its value. Each row describes a property. Note: W
hile some properties in the table are marked with the “Write” qualifier
(based on their designation in the DMTF CIM schema), all properties are in fact read-only for this version of the HP-UX LVM Provider.
Property Name Property Inheritance Property Description (and value)
HPUX_VolumeGroup REF Antecedent
[key]
Local to HPUX_PVInVG HP-UX: Has lower level StorageExtent.
HPUX_PhysicalVolume REF Dependent;
[key]
Local to HPUX_PVInVG HP-UX: Has the higher level StorageExtent.
Table7: HPUX_PVGInVG Properties - HPUX_PVGInVG is an association describing the Physical Volume Groups which are part of a Volume Group.
Table 7 describes the properties of the HPUX_PVGInVG association class. It has three columns. The first is the property name (including type and
units), the second is the property inheritance (indicating which class or super class defines the property), and the third is the property’s description
