HP Virtual Connect Enterprise Manager 7.1 Release Notes

NOTE: Keep in mind that some VC features are not validated or replicated by VCEM. For more
information, see the HP Virtual Connect Enterprise Manager 7.1 User Guide available at http://
www.hp.com/go/vcem/
Fixes
The primary objective of this release is to support the latest HP hardware platforms, support the
latest revisions of already supported operating systems and hypervisors, and to fix software issues.
This release offers improvements in the following areas:
• VC Manager connection status is now included in the VCEM profile.
• VC Manager profile status is now displayed in the VCEM GUI.
• VCEM domain groups running FW version 3.18 (or earlier) with VLAN tunneling enabled will
not experience network connectivity loss when you upgrade domains to FW version 3.30 (or
later) using the "Complete Maintenance" function. The issue described in Customer Advisory
document ID c03264140 available at http://h20000.www2.hp.com/bizsupport/TechSupport/
Document.jsp?objectID=c03264140 has been fixed.
Prerequisites
• VCEM 7.1 can be used for an initial VCEM installation, or it can be used to update existing
installations of VCEM 6.0 or later, if they are installed on a 64 bit Windows system. For more
information, see theHP Insight Management 7.1 Support Matrix available at http://
www.hp.com/go/insightmanagement/docs and the HP Virtual Connect Enterprise Manager
7.1 User Guide available at http://www.hp.com/go/vcem/. VCEM 7.1 can be downloaded
at http://www.hp.com/go/vcem/.
• Hardware, firmware, and software requirements for this release are listed in the HP Insight
Management 7.1 Support Matrix available in the Insight Management Information Library at
http://www.hp.com/go/insightmanagement/docs.
• Installation and upgrade prerequisites are documented in the HP Virtual Connect Enterprise
Manager 7.1 User Guide available in the Insight Management Information Library at http://
www.hp.com/go/insightmanagement/docs.
• To download the latest Virtual Connect firmware, see the HP Virtual Connect Firmware &
Upgrades web page at http://h18000.www1.hp.com/products/blades/components/
vc-compmatrix.html.
IMPORTANT: For compatibility and correct VCEM operation, the HP Virtual Connect Manager
and associated firmware on all managed domains must be version 3.15, or later. For more
information about supported Virtual Connect firmware, see the HP Virtual Connect Enterprise
Manager 7.1 User Guide available in the Insight Management Information Library at http://
www.hp.com/go/insightmanagement/docs.
Installation instructions
Installation instructions are documented in the HP Virtual Connect Enterprise Manager 7.1 User
Guide available at http://www.hp.com/go/vcem/.
Issues and suggested actions
VC firmware compatibility mode limitations when adding a domain, or updating
domain firmware
VC group firmware mode is the firmware level that a domain group operates at. VC firmware
compatibility mode allows administrators to update each domain in a domain group incrementally,
