the setting was disabled during creation of the user. If LOCALS~1 is displayed, the user was created
while this setting was enabled.
If the user was created while the setting was enabled:
2010/01/01 18:26 <DIR> LOCALS~1 Local Settings
If the user was created while the setting was disabled:
2010/01/01 18:26 <DIR>
Terminal service (Windows)
You cannot execute the Command View Advanced Edition Suite installer as a RemoteApp in the
terminal service of Windows Server 2008 or Windows Server 2008 R2.
Symbolic links (Linux)
Ensure that the symbolic links indicated in the following table are not set. If any are set, installation
might not be successful.
LocationSymbolic link destination
/optFile system for installation
/var/optLog output directory
/var/tmpTemporary directory
Under /opt/CVXPAE
5
Installation directory for the Device Manager server and any
directories under the installation directory
Under /var/opt/CVXPAE
5
Installation directory for Command View Advanced Edition
Suite products and any directories under the installation
directory
Under /var/opt/CVXPAE /database
5
Installation directory for the Common Component database
and any directories under the installation directory
Under /var/opt/CVXPAE /database/Base
5
Under /var/opt/CVXPAE/database/DeviceManager
5
Installation directory for the Device Manager server database
and any directories under the installation directory
Under /var/opt/ CVXPAE /database/HTSM
5
Installation directory for the Tiered Storage Manager server
database and any directories
Under /var/opt/ CVXPAE /database/HRpM
5
Installation directory for the Replication Manager server
database and any directories
5
This is the default installation directory.
Permissions for the installation directory
Grant all users read and execution permissions to the installation directory, as well as all directories
below it. In Linux, the directory specified as the installation directory will have its permissions set to
775. Specify an installation directory for which there will be no issues if the permissions are changed
to 775.
Host Data Collector service
If the Bourne shell is used to install Host Data Collector or to start the service, logging out of the
management server causes the Host Data Collector service to stop. Therefore, use a shell other than
the Bourne shell to install Host Data Collector or start the service.
Important considerations 41
