Setting properties for event notification
By setting information such as SMTP server information and a notification-source email address for
the following properties in the Device Manager server server.properties file, the execution
results for events related to Tiered Storage Manager can be sent via email:
• server.mail.enabled
• server.mail.from
• server.mail.smtp.host
• server.mail.smtp.port
• server.mail.smtp.auth
• server.mail.errorsTo
• server.eventNotification.mail.to
TIP:
To send notifications about executed tasks via the Tiered Storage Manager CLI or the Tiered Storage
Manager GUI in Legacy mode, the following properties in the Tiered Storage Manager server
server.properties file must be set:
• server.mail.from
• server.mail.smtp.host
• server.mail.smtp.port
• server.mail.smtp.auth
• server.mail.errorsTo
• server.eventNotification.mail.to
• server.eventMonitoringIntervalInMinute
Customizing event notification templates
The content of emails sent to users as event notifications are set in template files. You can edit the
template files to customize the contents of emails as necessary and set which items to send notifications
out for.
Setting up logs and alerts144
