SolutionProblem and causeNo.
PROBLEM: An inconsistency exists
between the database information
and the storage system status.
CAUSE: Possible causes are as
follows:
• The Tiered Storage Manager
server terminated abnormally due
to a forced termination or an un-
expected error.
• A failover occurred in a cluster
environment.
3
Troubleshooting284
