server.migrationPlan.candidateVolumeCountLimit
Specify whether to limit the number of candidate volumes that are displayed when creating a migration
plan.
Specify a Boolean value for this property. If you specify true, the number of displayed candidate
volumes will be limited. If you specify false, there will be no limit imposed on the number of displayed
candidate volumes.
Default: true
server.migrationPlan.candidateCapacityGroupDisplayMaxCount
Specify how many volumes with a larger capacity than the migration source volume to display in
addition to the volumes with the same capacity as the migration source volume when creating a
migration plan.
You can specify a value from 0 to 10. Specify 0 to display only volumes with the same capacity as
the migration source volume.
Default: 4
CAUTION:
• If you specify a volume with a larger capacity than the migration source volume for the migration
target volume, the migration target volume is deleted prior to migration, and then created again
with the same capacity as the migration source volume. Therefore, the migration task will require
more time than when migrating to a volume of the same capacity.
• If the migration target volume is re-created, the free capacity of the parity group increases by the
difference in capacity with the migration source volume. For example, if a volume that has 30 GB
is specified as a migration target for a migration source volume that has 10 GB, the free capacity
of the parity group increases by 20 GB. Therefore, we recommend that you specify, as a migration
target, a volume that is as close in capacity to the migration source volume as possible.
server.migration.maxRetryCount
Specify the maximum number of retries to be sent by the Tiered Storage Manager server when
requesting that the storage system retry task execution.
If the storage system is temporarily unable to receive such requests because the user has modified the
configuration of the storage system or the storage system is operating in Modify mode, requests to
the storage system can be retried every five minutes.
You can specify a value from 0 to 2,147,483,647. If 0 is specified, no retries are attempted.
Default: 5
server.migration.waitForPairDeleteInMinute
Specify the number of minutes to wait after a migration finishes until a storage system will split a
migration pair.
Storage systems refresh themselves after a migration on them finishes. Specify this value to make sure
that a migration pair is not split on a storage system while that storage system is refreshing.
Administrator Guide (Web Version) 381
