• The P-VOL and S-VOL must be managed by a single management server (Device Manager
server).
• The P-VOL and S-VOL must be recognized by the hosts (application servers).
We recommend that P-VOL and S-VOL be assigned to separate application servers.
• From the P-VOL and S-VOL, LUN security must be set for the host (application server).
The pair management server does not need to recognize the P-VOL or S-VOL.
Command device conditions:
• The management server must recognize a command device.
The command device security must not be used for a command device.
• From a command device, LUN security must be set for the pair management server.
To manage copy pairs for Continuous Access or Continuous Access Journal, LUN security
must be set for the host, from the command devices of the storage systems of both the P-VOL
and S-VOL.
CAUTION:
If the pair management server is connected to a command device whose
authentication mode is enabled, you need to authenticate users by executing the
raidcom command on the pair management server before performing copy pair
operations from the GUI or CLI. If the application server OS is Windows, you need
to authenticate users as a Device Manager agent service (HBsA Service) execution
user.
Resource group conditions (when managing partitioned resources in P9500):
• The volumes below, or a storage system containing the volumes below, must be registered in
a resource group managed by the user.
- P-VOL
- S-VOL
- All pool volumes that make up a pool (when managing Snapshot or Fast Snap pairs)
- All journal volumes that make up a journal (when managing Continuous Access Journal pairs)
• A shared resource group in which a command device has been registered must be created
and assigned to each user.
Note that, if each user uses a different command device, register the command device in a
resource group managed by the users, instead of registering them in a shared resource group.
Related topics:
• How to install RAID Manager: RAID Manager documentation
• Changing Device Manager agent properties, page 401
• server.agent.rm.centralizePairConfiguration, page 412
• Storage system requirements for managing copy pairs, page 66
• Prerequisite version of the Device Manager agent for managing copy pairs , page 68
System configuration for using a virtual command device server configuration to manage
copy pairs
Set up the management server, hosts (application servers), virtual command device server, and storage
system so that the prerequisites are satisfied.
