2 Network configuration
This chapter describes the settings for the P9000 Command View AE Suite products that are required
in various network configurations.
Port settings
This section describes the port numbers and firewall settings used by the P9000 Command View AE
Suite products.
Ports used by P9000 Command View AE Suite products
Avoid specifying port numbers used by other programs installed on the same computer for the port
numbers used by P9000 Command View AE Suite products.
If the same port number is set, either change the setting for the other program or change the setting
for the P9000 Command View AE Suite product.
TIP:
Some port numbers are part of the port numbers that are temporarily assigned by OSs. If the port
numbers used by the P9000 Command View AE Suite products are set in the services file of the
OS, the port numbers can be excluded from the port numbers that can be temporarily assigned by
the OS.
Ports used by Common Component
For the management server, ensure that the port numbers specified for use by Common Component
are different from the port numbers used by other programs installed on the same computer.
Table 12 Ports used by Common Component
DescriptionPort number
Used for accessing the HBase Storage Mgmt Web Service when communicating
with management clients (GUI).
This port number can be changed.
23015/tcp
#1
Used for accessing the HBase Storage Mgmt Web Service when performing SSL
communication with management clients (GUI).
This port number can be changed.
23016/tcp
Used internally for Common Component communication (communication with
the Web server).
This port number can be changed.
23017/tcp
Administrator Guide (Web Version) 71
