Installing and Configuring HSG Agent
4–9HSG80 ACS Solution Software Version 8.7 for Compaq Tru64 UNIX Installation and
Configuration Guide
4–9
23. Press press the Enter key.
The software asks if the displayed information is correct.
24. If the displayed information is correct, select option y and press the Enter key.
A message, asking if you would like to add another person to notify, appears.
25. Select option n to end the dialog or y to add another person to notify. Press press
the Enter key.
After you select option n, the system will start the new Agent. If the installation
script detects a problem at Agent startup, it will alert you.
You are asked if you are running Agent in a TruCluster environment.
NOTE: SWCC in A TruCluster environment (Appendix) goes into detail on how to setup the
SWCC Agent in a TruCluster Environment.
Final System Configuration
26. Do one of the following:
— If you are running the Agent in cluster, select option y. The software is
configured to scan the SCSI-bus for subsystems at startup.
— If you are not running the Agent in a cluster, select option n. The software is
configured to look at the storage.ini file at startup time. The storage.ini file
contains the listing of your subsystems.
NOTE: StorageWorks recommends that if you are running Tru64 UNIX 5.1x, especially within a
fabric, configure the software to scan the SCSI-bus at startup. When asked if running the Agent
in a cluster, answer y.
The system starts the new Agent.
27. Enter the following and press the Enter key to unmount the CD-ROM:
# cd /
# umount /mnt
Information Provides messages, but they do not indicate that something is
broken. Examples of informational messages are the following: an
Agent startup message or a message saying that an error has
been resolved.
Table 4–5: Definitions of Email Notification Options
Term Definition
