5–1HSG80 ACS Solution Software Version 8.7 for Compaq Tru64 UNIX Installation and
Configuration Guide
5
FC Configuration Procedures
This chapter describes procedures to configure a subsystem that uses Fibre Channel
(FC) fabric topology. In fabric topology, the controller connects to its hosts through
switches.
The following information is included in this chapter:
• “Establishing a Local Connection,” page 5–2
• “Setting Up a Single Controller,” page 5–3
• “Setting Up a Controller Pair,” page 5–10
• “Configuring Devices,” page 5–16
• “Configuring Storage Containers,” page 5–16
• “Assigning Unit Numbers and Unit Qualifiers,” page 5–22
• “Configuration Options,” page 5–23
• “Verifying Storage Configuration from Host,” page 5–27
Use the command line interpreter (CLI) or StorageWorks Command Console (SWCC)
to configure the subsystem. This chapter uses CLI to connect to the controller. To use
SWCC for configuration, see the SWCC online help for assistance.
IMPORTANT: These configuration procedures assume that controllers and cache modules are
installed in a fully functional and populated enclosure and that the PCMCIA cards are installed.
To install a controller or cache module and the PCMCIA card, see the StorageWorks
HSG60/HSG80 Array Controller ACS Version 8.7 Maintenance and Service Guide.
