Using CLI for Configuration
6–3HSG80 ACS Solution Software Version 8.7 for Compaq Tru64 UNIX Installation and
Configuration Guide
6–3
TRU64_UNIX hosts. Port 1 link is separate from port 2 link (that is, ports 1 of both
controllers are on one loop or fabric, and port 2 of both controllers are on another)
therefore, each adapter has two connections.
.
Figure 6–2: Representative multiple-bus failover
Figure 6–3: Example, three non-clustered host systems
Figure 6–4 represents units that are logical or virtual disks comprised of storagesets
configured from physical disks.
CXO7109B
Host
port 1
active
Host
port 2
active
Host
port 2
active
Host
port 1
active
D101 D102 D120
D0 D1
D2
Host 1
"RED"
Controller A
Controller B
All units visible to all ports
FCA1 FCA2
Host 2
"GREY"
FCA1 FCA2
Host 3
"BLUE"
FCA1 FCA2
Connections
RED1B1
GREY1B1
BLUE1B1
Connections
RED2A2
GREY2A2
BLUE2A2
Connections
RED2B2
GREY2B2
BLUE2B2
Connections
RED1A1
GREY1A1
BLUE1A1
Switch
or hub
Switch
or hub
NOTE: FCA = Fibre Channel Adapter
