Using CLI for Configuration
6–5HSG80 ACS Solution Software Version 8.7 for Compaq Tru64 UNIX Installation and
Configuration Guide
6–5
SET THIS SCSI_VERSION=SCSI-3
SET THIS PORT_1_TOPOLOGY=FABRIC
SET THIS PORT_2_TOPOLOGY=FABRIC
SET OTHER PORT_1_TOPOLOGY=FABRIC
SET OTHER PORT_2_TOPOLOGY=FABRIC
SET THIS ALLOCATION_CLASS=0
RESTART OTHER
RESTART THIS
SET THIS TIME=10-Mar-2001:12:30:34
RUN FRUTIL
Y
Plug serial cable from maintenance terminal into bottom controller.
NOTE: Bottom controller (B) becomes “this” controller.
RUN FRUTIL
Y
SET THIS MIRRORED_CACHE
NOTE: This command causes the controllers to restart.
SET THIS PROMPT=“BTVS BOTTOM”
SET OTHER PROMPT=“BTVS TOP”
SHOW THIS
SHOW OTHER
Plug in the Fibre Channel cable from thefirst adapter in host “RED.”
SHOW CONNECTIONS
RENAME !NEWCON00 RED1B1
SET RED1B1 OPERATING_SYSTEM=TRU64_UNIX
RENAME !NEWCON01 RED1A1
SET RED1A1 OPERATING_SYSTEM=TRU64_UNIX
SHOW CONNECTIONS
Do you intend to replace this controller's cache
battery? Y/N [Y]
Do you intend to replace this controller's cache
battery? Y/N [Y]
