Using CLI for Configuration
6–6 HSG80 ACS Solution Software Version 8.7 for Compaq Tru64 UNIX Installation and
Configuration Guide
NOTE: Connection table sorts alphabetically.
Mark or tag both ends of Fibre Channel cables.
Plug in the Fibre Channel cable from the second adapter in host “RED.”
SHOW CONNECTIONS
Connection
Name
Operating
System
Controll
er
Port Address Status
Unit
Offset
RED1A1 TRU64_UNIX OTHER 1 XXXXX
X
OL other 0
HOST_ID=XXXX-XXXX-XXXX-XXXX ADAPTER_ID=XXXX-XXXX-XXXX-XX
XX
RED1B1 TRU64_UNIX THIS 1 XXXXX
X
OL this 0
HOST_ID=XXXX-XXXX-XXXX-XXXX ADAPTER_ID=XXXX-XXXX-XXXX-XX
XX
