Backing Up, Cloning, and Moving Data
7–6 HSG80 ACS Solution Software Version 8.7 for Compaq Tru64 UNIX Installation and
Configuration Guide
CAUTION: Never initialize any container or this procedure will not protect data in the
storageset.
Use the following procedure to move a storageset, while maintaining the data the
storageset contains:
1. Show the details for the storageset you want to move. Use the following
command:
SHOW STORAGESET-NAME
2. Label each member with its name and PTL location.
If you do not have a storageset map for your subsystem, you can enter the LOCATE command
for each member to find its PTL location. Use the following command:
LOCATE DISK-NAME
To cancel the locate command, enter the following:
LOCATE CANCEL
3. Delete the unit number shown in the “Used by” column of the SHOW storageset-name
command. Use the following syntax:
DELETE UNIT-NUMBER
4. Delete the storageset shown in the “Name” column of the SHOW storageset-name
command. Use the following syntax:
DELETE STORAGESET-NAME
5. Delete each disk drive, one at a time, that the storageset contained. Use the
following syntax:
DELETE DISK-NAME
DELETE DISK-NAME
DELETE DISK-NAME
6. Remove the disk drives and move them to their new PTL locations.
7. Again add each disk drive to the controller's list of valid devices. Use the
following syntax:
ADD DISK DISK-NAME PTL-LOCATION
ADD DISK DISK-NAME PTL-LOCATION
ADD DISK DISK-NAME PTL-LOCATION
