Subsystem Profile Templates
A–4 HSG80 ACS Solution Software Version 8.7 for Compaq Tru64 UNIX Installation and
Configuration Guide
Storage Map Template 1 for the BA370 Enclosure
Use this template for:
• BA370 single-enclosure subsystems
• first enclosure of multiple BA370 enclosure subsystems
Port
1 2 3 4 5 6
Power
Supply
D10300 D20300 D30300 D40300 D50300 D60300
Power
Supply
3
Tar gets
Power
Supply
D10200 D20200 D30200 D40200 D50200 D60200
Power
Supply
2
Power
Supply
D10100 D20100 D30100 D40100 D50100 D60100
Power
Supply
1
Power
Supply
D10000 D20000 D30000 D40000 D50000 D60000
Power
Supply
0
