About this Guide
xxiHSG80 ACS Solution Software Version 8.7 for Compaq Tru64 UNIX Installation and
Configuration Guide
Figure 2: General configuration flowchart (panel 2)
Create Storagesets
and Partitions:
Stripeset, Page 5-17
Mirrorset, Page 5-18
RAIDset, Page 5-19
Striped Mirrorset, Page 5-19
Single (JBOD) Disk, Page 5-20
Partition, Page 5-20
Assign Unit Numbers
Page 5-22
Continue creating units
until you have you have
completed your planned
configuration.
Configure devices
Page 5-16
Configuration Options
Page 5-23
Verify Storage Setup
A
