SWCC Agent in TruCluster Environment
C–12 HSG80 ACS Solution Software Version 8.7 for Compaq Tru64 UNIX Installation and
Configuration Guide
Running the SWCC Agent on a V5.x Cluster
This section is intended for users of Tru64 UNIX V5.x. Running SWCC on a V5.x
Cluster has the following requirements:
The SWCC Tru64 UNIX agent installation script is not cluster-aware. It adds swcc
and S500swcc entries to the /sbin/init.d and /sbin/rc3.d directories, respectively, and
starts the steamd daemon on the system.
Table C–1: Configuration Requirements
Requirement Description
Operating System Tru64 UNIX Version 5.0 or higher and TruCluster
Server Version 5.0A or higher.
Supported Controllers and
Minimum Firmware
Versions
The supported firmware has locking features that
prevent data corruption resulting from access by
multiple systems. The supported combinations of
controllers and minimum firmware versions are as
follows.
HSZ40 3.7; HSZ50 5.7; HSZ70 7.7
HSZ80 8.3-1; HSG80 8.5; HSG60 8.5L
Earlier versions of the firmware are explicitly not
supported.
HSZ40 3.7
HSZ50 5.7
HSZ70 7.7
HSZ80 8.3-1
HSG80 8.5
HSG60 8.5L
Earlier versions of the firmware are explicitly not
supported.
Disk Space Required for
Agent
2 MB free space in /tmp directory. 4 MB free space for
the Agent installation directory.
Skill Level Requirements This procedure is intended for experienced system
administrators or programmers. Familiarity with shell
programming and access to the root of the TruCluster
Server Cluster is required.
