SWCC Agent in TruCluster Environment
C–20 HSG80 ACS Solution Software Version 8.7 for Compaq Tru64 UNIX Installation and
Configuration Guide
Install and Run the Agent on One Cluster Member
We recommend that you run the SWCC agent on only one cluster member and use
CAA for failover. The SWCC Navigation Window treats cluster members as
standalone systems. That is, the Navigation Window does not include a cluster
management object; you initiate all management tasks at the system (member) level. If
you were to add each cluster member to the Navigation Window, each member would
be displayed as a standalone system and would appear to have ownership of the
controllers attached to it, which might be confusing at first glance.
Follow these steps to install the agent software on a TruCluster Server cluster member:
1. Insert the storage subsystem CD-ROM in the CD-ROM drive.
2. Mount the CD-ROM with the command:
# mount -r -t cdfs /dev/disk/cdrom0c /mnt
where cdrom0c is the name of the CD-ROM drive.
3. Change to the Command Console directory with the following command:
# cd /mnt/agent
4. 4. Execute the installation script with this command:
# setld -l
5. 5. Follow the online instructions to install the software.
The agent installation procedure requires details about the configuration, including the
information listed in the following table:
Table C–2: Required Configuration Details
Property Description
The host name of the client
systems
Network names for the computers (PCs) on which the
Command Console Client (the GUI) will be running.
Password Required of the client system to gain configuration access.
Access level The amount of control to be granted to the client system. If
you want to restrict the type of access from a client, you
must specify a password. The possible options are:
0 Overall status
1 Detailed status
2 Configuration and Status
