Planning Storage Configurations
2–8 HSG80 ACS Solution Software Version 8.7 for Compaq Tru64 UNIX Installation and
Configuration Guide
Table 2–1: PTL addressing, single-bus configuration, six Model 4310R
enclosures
Model 4310R Disk Enclosure Shelf 6 (single-bus)
Bay 1 2 3 4 5 6 7 8 9 10
SCSI
ID
00 01 02 03 04 05 08 10 11 12
DISK
ID
Disk60000
Disk60100
Disk60200
Disk60300
Disk60400
Disk60500
Disk60800
Disk61000
Disk61100
Disk61200
Model 4310R Disk Enclosure Shelf 5 (single-bus)
Bay 1 2 3 4 5 6 7 8 9 10
SCSI
ID
00 01 02 03 04 05 08 10 11 12
DISK
ID
Disk50000
Disk50100
Disk50200
Disk50300
Disk50400
Disk50500
Disk50800
Disk51000
Disk51100
Disk51200
Model 4310R Disk Enclosure Shelf 4 (single-bus)
Bay 1 2 3 4 5 6 7 8 9 10
SCSI
ID
00 01 02 03 04 05 08 10 11 12
DISK
ID
Disk40000
Disk40100
Disk40200
Disk40300
Disk40400
Disk40500
Disk40800
Disk41000
Disk41100
Disk41200
Model 4310R Disk Enclosure Shelf 1 (single-bus)
Bay 1 2 3 4 5 6 7 8 9 10
SCSI
ID
00 01 02 03 04 05 08 10 11 12
DISK
ID
Disk10000
Disk10100
Disk10200
Disk10300
Disk10400
Disk10500
Disk10800
Disk11000
Disk11100
Disk11200
