Planning Storage Configurations
2–13HSG80 ACS Solution Software Version 8.7 for Compaq Tru64 UNIX Installation and
Configuration Guide
2–13
Table 2–4: PTL addressing, dual-bus configuration, three Model 4354A
enclosures.
Model 4354R Disk Enclosure Shelf 1 (dual-bus)
SCSI Bus A SCSI Bus B
Bay 1 2 3 4 5 6 7 8 9 10 11 12 13 14
SCSI
ID
00 01 02 03 04 05 08 00 01 02 03 04 05 08
DISK
ID
Disk10000
Disk10100
Disk10200
Disk10300
Disk10400
Disk10500
Disk10800
Disk20000
Disk20100
Disk20200
Disk20300
Disk20400
Disk20500
Disk20800
Model 4354R Disk Enclosure Shelf 2 (dual-bus)
SCSI Bus A SCSI Bus B
Bay 1 2 3 4 5 6 7 8 9 10 11 12 13 14
SCSI
ID
00 01 02 03 04 05 08 00 01 02 03 04 05 08
DISK
ID
Disk30000
Disk30100
Disk30200
Disk30300
Disk30400
Disk30500
Disk30800
Disk40000
Disk40100
Disk40200
Disk40300
Disk40400
Disk40500
Disk40800
Model 4354R Disk Enclosure Shelf 3 (dual-bus)
SCSI Bus A SCSI Bus B
Bay 1 2 3 4 5 6 7 8 9 10 11 12 13 14
SCSI
ID
00 01 02 03 04 05 08 00 01 02 03 04 05 08
DISK
ID
Disk50000
Disk50100
Disk50200
Disk50300
Disk50400
Disk50500
Disk50800
Disk60000
Disk60100
Disk60200
Disk60300
Disk60400
Disk60500
Disk60800
