HP Insight Management WBEM Providers SNMP Data Migration for vSphere 5.1 U2 September 2013
Table Of Contents
- 1 Introduction
- 2 Overview of the Insight Management MIB
- 3 High Level Mapping
- 4 Server MIB Variable to WBEM Property Mappings
- 5 Storage MIB Variable to WBEM Property Mappings
- 6 Network MIB Variable to WBEM Property Mappings
- 7 Server Trap to Indication Mappings
- 8 Storage Trap to Indication Mappings
- 9 Network Trap to Indication Mappings
- 10 Revisions
WBEM Class and Property
SMX_Fan.DeviceID
Notes
MIB OID
1.3.6.1.4.1.232.6.2.6.7.1.3
MIB OID Name
cpqHeFltTolFanLocale
WBEM Class and Property
SMX_Fan.FanType
Notes
MIB OID
1.3.6.1.4.1.232.6.2.6.7.1.4
MIB OID Name
cpqHeFltTolFanPresent
WBEM Class and Property
Not Implemented
Notes
No property explicitly for “IsPresent”, but an instance
implies presence.
MIB OID
1.3.6.1.4.1.232.6.2.6.7.1.5
MIB OID Name
cpqHeFltTolFanType
WBEM Class and Property
SMX_Fan.FanType
Notes
MIB OID
1.3.6.1.4.1.232.6.2.6.7.1.6
MIB OID Name
cpqHeFltTolFanSpeed
WBEM Class and Property
SMX_FanSpeedSensor.CurrentReading
Notes
MIB OID
1.3.6.1.4.1.232.6.2.6.7.1.7
MIB OID Name
cpqHeFltTolFanRedundant
WBEM Class and Property
SMX_FanRedundancySet.RedundancyStatus
Notes
MIB OID
1.3.6.1.4.1.232.6.2.6.7.1.8
MIB OID Name
cpqHeFltTolFanRedundantPartner
WBEM Class and Property
SMX_FanRedundancySet.InstanceID
Notes
All fans within a specific fan redundancy set are considered
to be partners.
