HP Insight Management WBEM Providers SNMP Data Migration for vSphere 5.1 U2 September 2013
Table Of Contents
- 1 Introduction
- 2 Overview of the Insight Management MIB
- 3 High Level Mapping
- 4 Server MIB Variable to WBEM Property Mappings
- 5 Storage MIB Variable to WBEM Property Mappings
- 6 Network MIB Variable to WBEM Property Mappings
- 7 Server Trap to Indication Mappings
- 8 Storage Trap to Indication Mappings
- 9 Network Trap to Indication Mappings
- 10 Revisions
MIB OID
1.3.6.1.4.1.232.8.2.1.1.11
MIB OID Name
cpqSsBoxFltTolPwrSupplyStatus
WBEM Class and Property
SMX_SAStorageEnclosureProcessor.OperationalStatus
SMX_SASStorageEnclosureProcessor.OperationalStatus
Notes
MIB OID
1.3.6.1.4.1.232.8.2.1.1.12
MIB OID Name
cpqSsBoxBackPlaneVersion
WBEM Class and Property
Not Implemented
Notes
MIB OID
1.3.6.1.4.1.232.8.2.1.1.13
MIB OID Name
cpqSsBoxTotalBays
WBEM Class and Property
SMX_SADriveCage.DriveBays
SMX_SASDriveCage.DriveBays
Notes
MIB OID
1.3.6.1.4.1.232.8.2.1.1.14
MIB OID Name
cpqSsBoxPlacement
WBEM Class and Property
SMX_SADriveCage.Location
SMX_SASDriveCage.Location
Notes
MIB OID
1.3.6.1.4.1.232.8.2.1.1.15
MIB OID Name
cpqSsBoxDuplexOption
WBEM Class and Property
SMX_SADriveCage.DuplexLocation
SMX_SASDriveCage.DuplexLocation
Notes
MIB OID
1.3.6.1.4.1.232.8.2.1.1.16
MIB OID Name
cpqSsBoxBoardRevision
WBEM Class and Property
Not Implemented
Notes
MIB OID
1.3.6.1.4.1.232.8.2.1.1.17
